Efficient 3D Printing Solutions for Your Needs

Your On-Demand Manufacturing Partner: Fast, Global, Reliable

3D Printing



At XLC, we specialize in delivering top-tier 3D printing services through a diverse range of additive manufacturing technologies. Our comprehensive offerings include Fused Deposition Modeling (FDM), Stereolithography (SLA), Selective Laser Sintering (SLS), and Selective Laser Melting (SLM), enabling the precise fabrication of both plastic and metal components. Whether you require intricate prototypes or scalable production runs, our versatile solutions cater to your unique needs.3D printing excels in producing custom, one-off components and small batch runs, offering unparalleled flexibility and efficiency. Additionally, it unlocks the potential to create complex geometries that are impossible to achieve with conventional manufacturing methods. With XLC, you can bring your most intricate designs to life, transforming innovation into reality.

Cost-Effective Innovation

3D printing stands out as an exceptionally cost-efficient manufacturing solution, especially for one-off parts and small production runs. By utilizing only the precise amount of material needed and eliminating the need for expensive tooling, this technology significantly reduces waste and lowers production costs. Whether you’re creating a single prototype or a small batch, 3D printing offers an accessible and affordable pathway to bring your ideas to life without compromising on quality or precision.

Precision Engineering in Complex Shapes

Advanced 3D printers construct components layer by layer through computer-precision control, enabling the creation of highly intricate and complex geometries. This technology allows for the design and production of parts with sophisticated internal structures that are impossible to achieve with traditional manufacturing methods. Whether it’s intricate lattices or multi-layered components, 3D printing unlocks the potential to bring even the most complex designs to life with unparalleled accuracy.

Rapid Production with Minimal Setup

With 3D printing, the transition from design to finished part is remarkably swift. Once a part is modeled using CAD software, it can be printed within hours, bypassing the need for extensive setup procedures. This streamlined process significantly reduces lead times and allows for rapid iteration, making it an ideal solution for quick prototyping and on-demand manufacturing.

Flexibility and Risk Reduction

One of the key advantages of 3D printing is its adaptability. Since no tooling is required, the process inherently carries lower risks. If a design flaw is detected after printing, the issue can be easily corrected digitally. There’s no need to invest in costly tooling replacements, making it a highly flexible and cost-effective solution for iterative design and production.

Sustainability in Manufacturing

While 3D printers do consume energy during operation, they offer a significant advantage in terms of material efficiency. Unlike subtractive manufacturing methods such as machining, which often generate substantial waste material, 3D printing uses only the exact amount of material needed to create a part. This additive approach minimizes waste and contributes to a more sustainable and environmentally friendly manufacturing process.

What is 3D Printing?

3D printing, also known as additive manufacturing, is a transformative manufacturing technique that constructs objects layer by layer. The process begins with a computer sending detailed instructions to the 3D printer, which then deposits or solidifies material according to a preprogrammed design, building up layers sequentially.
There are various types of 3D printers, each designed to work with different materials—some for plastics, others for metals, and even more for specialized materials. Despite their differences, these technologies share common principles.
3D printing has revolutionized the manufacturing landscape by offering a streamlined, one-step production method. It allows businesses to set up compact, efficient printing stations in offices or small workshops, requiring minimal training to operate. Additionally, the low startup costs and affordable material options make it accessible for a wide range of applications.

How to Select the Right 3D Printing Process

If you need guidance on choosing the best 3D printing process for your needs, our team of additive manufacturing experts is here to help. We offer a consultation and planning phase to ensure you select the ideal solution.
To get started, provide your 3D CAD files, which will be reviewed and optimized by our production team to meet the specific requirements of your chosen printing technology—whether it's FDM, SLA, SLS, or SLM. Each process has unique design considerations, so optimizing your CAD model is crucial for achieving the best results.

3D Printing Technologies

XLC offers a comprehensive suite of high-precision 3D printing (additive manufacturing) solutions, encompassing Fused Deposition Modeling (FDM), Stereolithography (SLA), Selective Laser Sintering (SLS), and Selective Laser Melting (SLM). These technologies enable the production of both plastic and metal components, catering to a wide range of applications from rapid prototyping to full-scale production.

3D printing is an ideal solution for creating single parts or small batch runs, offering unparalleled flexibility and efficiency. It allows for the realization of highly complex geometries that are unattainable through conventional manufacturing methods, unlocking new possibilities for innovation and design.

1.FUSED DEPOSITION MODELING (FDM)

Fused Deposition Modeling, or FDM, is a versatile 3D printing process that builds parts by extruding and layering molten thermoplastic material. This method is known for its accessibility, cost-effectiveness, and ability to produce durable parts quickly. FDM is ideal for creating functional prototypes, small batch production, and even end-use parts, making it a popular choice for a wide range of applications.

Advantages

  • Most affordable 3D printing process for plastic parts

  • Material options

  • Widely available

Disadvantages

  • Comparatively low resolution

  • Produces visible layer lines

Typical accuracy

  • ± 0.5% (desktop)

  • ± 0.15% (industrial)

Typical layer height

  • 50-400 microns

FDM Materials

ABS

Another widely used FDM material, ABS (Acrylonitrile Butadiene Styrene), is known for its high-temperature resistance.

PLA

PLA (Polylactic Acid) is the most popular FDM material, known for its affordability, rigidity, and strength. Additionally, PLA is available in a wide range of colors and blends, making it versatile for various applications.

PETG

PETG (Polyethylene Terephthalate Glycol) is renowned for its exceptional impact resistance and favorable thermal properties. Additionally, it is certified as food-safe, making it ideal for applications involving food contact.

Nylon

Nylon is a durable and flexible material, known for its high strength and resistance to wear and chemicals. However, it is susceptible to moisture absorption.

TPE/TPU

These thermoplastic filaments, combining plastic and rubber, create parts with exceptional flexibility.

PC

Polycarbonate (PC) filaments generate parts of remarkable strength, with excellent resistance to both heat and impact.

2.STEREOLITHOGRAPHY (SLA)

Stereolithography (SLA) is an additive manufacturing process that operates differently from FDM. In SLA 3D printing, a laser is used to create a 3D object by selectively curing areas of a photosensitive liquid resin. The laser hardens the resin layer by layer, forming a solid part.

The SLA process involves a moving platform submerged in a tank of liquid resin. After each layer is fully cured, the platform moves to allow the next layer to be formed, unlike FDM where the platform typically remains stationary. The laser in SLA is precisely directed using a system of mirrors.

While SLA is limited to photosensitive polymers, it excels in producing parts with high accuracy and fine details. Notably, SLA is one of the earliest forms of additive manufacturing, having been developed in the 1980s.

Advantages

  • High resolution

  • No visible layer lines; smooth finish

  • Option of clear materials

Disadvantages

  • Printers more expensive than FDM

  • Weak parts will degrade with sunlight

  • Extensive post-processing required

Typical accuracy

  • ± 0.5% (desktop)

  • ± 0.15% (industrial)

Typical layer height

  • 25-100 microns

Stereolithography Materials

Resin 8119

A commonly used SLA material offers temperature resistance up to 65°C, making it suitable for functional prototypes, tools, and electrical components.

Resin 8118H

A resin resembling nylon, renowned for its exceptional toughness and durability.

Resin 8338

Our highest-performing resin in terms of temperature resistance, capable of enduring temperatures up to 120°C.

Resin 8228

An ABS-like resin, known for its impact resistance and ability to withstand temperatures up to 70°C.

3.SELECTIVE LASER SINTERING (SLS)

Selective Laser Sintering (SLS) is a powerful additive manufacturing technology that uses a high-powered laser to selectively fuse particles of powdered materials, such as plastics, metals, ceramics, or glass, to create solid, three-dimensional objects.

The SLS process begins with a build platform and a powder bed, where a thin layer of material powder is spread across the platform. The laser then selectively sinters the powder according to the cross-section of the 3D model, binding the particles together to form a solid layer. After each layer is completed, the platform lowers, and a new layer of powder is spread, repeating the process until the part is fully built.

One of the key advantages of SLS is its ability to produce complex geometries without the need for support structures, as the unsintered powder acts as a natural support. This feature allows for the creation of intricate designs and functional parts with high accuracy and mechanical strength. Additionally, SLS offers a wide range of engineering-grade materials, including durable nylons, glass-filled composites, and flame-retardant options, making it suitable for both prototyping and end-use part production.

Advantages

  • Parts have consistent mechanical properties

  • No support structures

Disadvantages

  • Porosity

  • Rough surface finish

Typical accuracy

  • ± 0.3%

Typical layer height

  • 100-120 microns

SLS Materials

Nylon PA12

An SLS material known for its mechanical strength, thermal and chemical resistance, and long-term stability.

TPU

A material with exceptional elasticity, high tear and abrasion resistance, and reliable thermal performance.

Alumide

Nylon infused with aluminum offers enhanced rigidity and a distinctive metallic finish.

4.SELECTIVE LASER MELTING (SLM)

Selective Laser Melting (SLM) is a metal additive manufacturing technique designed for producing functional, end-use components. SLM machines utilize a high-powered laser to selectively melt and fuse metal powder particles, layer by layer, to create a three-dimensional object.

In an SLM printer, the metal powder is housed within a gas-filled chamber. The laser scans across the powder, melting the particles in the desired areas and bonding them together. Once a layer is fully formed, the build platform lowers, allowing the laser to process the next layer.

SLM enables the production of robust metal parts with intricate geometries, offering engineers unprecedented design flexibility and the ability to create complex, high-performance components.

Advantages

  • Strong and hard parts

  • Complex shapes

Disadvantages

  • Limited build size

  • High cost

Typical accuracy

  • ± 0.1mm

Typical layer height

  • 20-50 microns

SLM Materials

Titanium

Titanium alloys, such as 6Al-4V and 6Al-4V ELI, are known for their exceptional ability to withstand high temperatures, their excellent strength-to-weight ratio, and their superior corrosion resistance. These materials can also be heat-treated to achieve even higher strength.

Aluminum

Aluminum alloys, such as AlSi12 and AlSi10Mg, offer excellent strength and hardness, making them ideal for creating complex geometries and parts with thin walls.

Nickel

Nickel alloys exhibit remarkable resistance to heat, corrosion, and oxidation, ensuring robust performance in high-temperature applications and maintaining strength under extreme conditions.

Stainless Steel

Stainless steels offer excellent resistance to wear, corrosion, and abrasion, making them durable and reliable for a wide range of applications.

Cobalt

Cobalt-chrome alloys boast remarkable strength, hardness, and the ability to withstand high temperatures, rendering them perfectly suited for challenging and demanding applications.

Precious Metals

Metals such as gold, silver, and platinum are known for their ductility and offer an attractive, high-quality appearance.

3D Printing for Prototyping Solutions

Appliance Base Prototype

This is one of the projects we completed for a fashion design company. Initially, they ordered a flexible polymer prototype of this type and added SLS, which was very expensive. Using newly developed resins, we can make flexible prototypes via SLA at only 1/5 the cost. What's the reason? Well, just because the prototypes of these other services weren't accurate enough. Therefore, they believe they must outsource from Europe. However, when they approached the XLC team, the company quickly discovered that they had finally found a service provider that could meet their needs.
